Skid Steer Loader (XT750)

The proportional controlled pilot control lever is easy to operate and saves effort, the operator can get skilled to operate the machine in a short time and not easily get tired. The leveling valve can keep the bucket level during the boom lift. The cab is capacious and has good visibility, all the instruments are located at the front for easy inspection, and all the buttons and switches are within hand's reach. The safety rails can prevent the operator from leaving the seat unexpectedly, and there are also four safety measures to ensure the operator's safety. It adopts the commonly used quick coupler; All types of attachments can be installed quickly and conveniently. The pipe joint is also standard. And most of the attachments produced by other manufacturers can be applicable on XT750. The cab can be turned forward in a large angle. There are two modes to control the engine throttle: Manual and foot pedal control, which makes it much more convenient for the operator. Various kinds of attachments can be mounted on the cab. Bucket capacity M3 0.55 Rated load capacity kg 950 Max. Unloading height Mm 2365 Unloading distance Mm 625 Hoist time s <5 Time of 3 operations s <10 Breakout force KN 16 Wheelbase mm 1116 Wheel center distance mm 1475 Max. Travel speed Km/h 12.6 Engine Yanmar Model 4TNV98-ZNWL Type 4 stroke, water-cooled, In-line Rated power Kw 50.8 Rated rev R/min 2500 Machine size (L&times; W&times; H) mm 3625&times; 1830&times; 2093 Machine weight t 3.6 Tyre size 12-16.5
